Specifications; Plug Configurations; Electrical Rating Chart; Dimensions - Hatco Toast-Max TM-5 Installations- Und Bedienungshandbuch

Plug Configurations

Units are supplied from the factory with an electrical cord and
plug. Plugs are supplied according to the application.
ELECTRIC SHOCk HAzARD: Plug unit into a properly
grounded electrical receptacle of the correct voltage, size,
and plug configuration. If plug and receptacle do not
match, contact a qualified electrician to determine and
install proper voltage and size electrical receptacle.
NOTE: The specification label is located on the side of the unit.
See label for serial number and verification of unit
electrical information.

Electrical Rating Chart

Model Voltage
TM-5 220–240 (CE)
TM-5H 100
120
220–240 (CE)
TM-10 220–240 (CE)
TM-10H 120
220–240 (CE)

Dimensions

Width
Model (A)
290 mm
TM-5 and
(11-7/16")
TM-5H
TM-10 and 368 mm
TM-10H (14-1/2")
* Add 195 mm (7-3/4") to Overall Depth (B) for units equipped with a rear discharge tray.
Form No. TMCEM-0212
WARNING
Hertz Watts
50/60 1340–1595
50/60 1340
50/60 1340
50/60 1340–1595
50/60 1940–2300
50/60 1790
50/60 1940–2300
Overall Unit
Depth (B)* Depth (C)
523 mm 419 mm
(20-5/8") (16-1/2")
520 mm 419 mm
(20-1/2") (16-1/2")
A
E
D
F
Front View
NEMA 5-15P
BS-1363
NOTE: Receptacle not supplied by Hatco.
Amps Plug Configuration
6.1–6.6 CEE 7/7 Schuko, BS-1363, or AS 3112
13.4 NEMA 5-15
11.2 NEMA 5-15
6.1–6.6 CEE 7/7 Schuko, BS-1363, or AS 3112
8.8–9.6 CEE 7/7 Schuko, BS-1363, or AS 3112
14.9 NEMA 5-15
8.8–9.6 CEE 7/7 Schuko, BS-1363, or AS 3112
Height Chamber
(D) Width (E)
387 mm 186 mm
(15-1/4") (7-3/8")
387 mm 264 mm
(15-1/4") (10-3/8")
Dimensions
5

SPECIFICATIONS

CEE 7/7 Schuko
AS 3112
Plug Configurations
Shipping Weight
16 kg (36 lbs.)
16 kg (36 lbs.)
16 kg (36 lbs.)
16 kg (36 lbs.)
19 kg (41 lbs.)
19 kg (41 lbs.)
19 kg (41 lbs.)
Footprint
Width (F)
260 mm
(10-1/4")
338 mm
(13-3/8")
B
C
G
Side View
Footprint
Depth (G)
336 mm
(13-1/4")
336 mm
(13-1/4")
