Hatco TOAST-QWIK TQ-10 Installations- Und Bedienungshandbuch Seite 9

SPECIFICATIONS
Model Voltage
TQ-10 120
208
240
200
220-230 (CE)
230-240 (CE)
*
NEMA 5-20P for Canada
Shaded area reflects export models only.
NOTE: TQ-10 220-230 Volt (CE) and 230-240 Volt (CE) available with either CEE 7/7 Schuko, BS 1363 or AS 3112 plug.
See Plug Configurations for details.
Model Voltage
TQ-15 220-230 (CE)
230-240 (CE)
Shaded area reflects export models only.
NOTE: TQ-15 220-230 Volt (CE) and 230-240 Volt (CE) available with either CEE 7/7 Schuko, BS 1363 or AS 3112 plug.
See Plug Configurations for details.
Model Voltage
TQ-400 120
208
240
200
220-230 (CE)
230-240 (CE)
TQ-405 220-230 (CE)
230-240 (CE)
TQ-400BA 120
208
240
200
220-230 (CE)
230-240 (CE)
*
NEMA 5-20P for Canada
Shaded area reflects export models only.
NOTE: TQ-400, TQ-405 and TQ-400BA 220-230 Volt (CE) and 230-240 Volt (CE) available with either CEE 7/7 Schuko, BS 1363
or AS 3112 plug. See Plug Configurations for details.
Form No. TQ2CEM-0903
ELECTRICAL RATING CHART – TQ-10 MODELS
Hertz Watts
60 1800
60 1830
60 1830
50/60 2070
50/60 1866-2040
50/60 2040-2221
ELECTRICAL RATING CHART – TQ-15 MODELS
Hertz Watts
50/60 2131-2330
50/60 2040-2221
ELECTRICAL RATING CHART – TQ-400 SERIES
Hertz Watts
60 1800
60 2230
60 2230
50/60 2064
50/60 1860-2030
50/60 2030-2210
50/60 2131-2330
50/60 2030-2210
60 1780
60 1880
60 1880
50/60 1848
50/60 1765-1930
50/60 1930-2100
Amps Plug Configuration
15.0 NEMA 5-15P*
8.8 NEMA 6-15P
7.6 NEMA 6-15P
10.4 AS 3112
8.5-8.9 See Note
8.9-9.3 See Note
Amps Plug Configuration
9.7-10.1 See Note
8.9-9.3 See Note
Amps Plug Configuration
15.0 NEMA 5-15P*
10.7 NEMA 6-15P
9.3 NEMA 6-15P
10.3 AS 3112
8.5-8.8 See Note
8.8-9.2 See Note
9.7-10.1 See Note
8.8-9.2 See Note
14.8 NEMA 5-15P*
9.0 NEMA 6-15P
7.8 NEMA 6-15P
9.2 AS 3112
8.0-8.4 See Note
8.4-8.8 See Note
7
Shipping Weight
15 kg (34 lbs.)
15 kg (34 lbs.)
15 kg (34 lbs.)
15 kg (34 lbs.)
15 kg (34 lbs.)
15 kg (34 lbs.)
Shipping Weight
15 kg (34 lbs.)
15 kg (34 lbs.)
Shipping Weight
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
21 kg (46 lbs.)
