7. Specifications

*
Specifications for channel A
*
Specifications for channel B
*
Synchronous output
*
TTL output
*
Counter
*
General characteristics
Specifications for channel A
7.1 Waveform characteristics:
Waveform types: sine, square, pulse, DC (maximum frequency for square≤40MHz)
Waveform length: 4~16000 points
Amplitude resolution: 14 bits
Sampling rate: 400 MSa/s
Harmonic distortion: ≥50dBc (F <1MHz), ≥40dBc (1MHz<F<20MHz)
Total distortion: ≤0.5% (20Hz~100kHz)
Square rise/fall time: ≤20ns
7.2 Frequency characteristics:
Frequency range: 0Hz~50MHz (P4040) 0Hz~150MHz (P4045)
Resolution: 100mHz
Frequency accuracy: ±(5×10-5+ 100mHz)
Frequency stability: ±5×10-6/ 3hrs
7.3 Pulse characteristics:
Pulse width range: 10ns~20s
Duty: 0.1%~ 99.9% (Only display)
Pulse width accuracy: ±(5×10-5+ 10ns)
Resolution: 5ns
7.4 Amplitude characteristics:
Amplitude range: 2mVp-p~20Vp-p (High impedance, frequency = 30 MHz)
Resolution:
Accuracy:
Stability:
Flatness:
Output impedance:
7.5 Offset characteristics:(for the attenuation is 0dB)
Offset ranges:
±(0~4V-Vpp/2)(high impedance A<4V);
±(0~10V-pp/2)(high impedance A>4V)
Resolution: 20mV
Offset accuracy: ±(1% + 10mV)
2mVp-p~15Vp-p (High impedance, frequency = 40 MHz)
2mVp-p~6Vp-p (High impedance, frequency > 40 MHz)
1mVp-p~10Vp-p ( 50 Ω, frequency = 30 MHz)
1mVp-p~7.5Vp-p ( 50 Ω, frequency = 40 MHz)
1mVp-p~3Vp-p ( 50 Ω, frequency > 40 MHz)
20mVp-p (A>2V),
2mVp-p (0.2V<A=2V),
0.2mVp-p (A=0.2V)
±(1% + 2mV)((High impedance, RMS, Frequency 1kHz)
±0.5%/ 3 hour
(1 kHz Sine)
±5% (F<1MHz)
±10% (1MHz=F<10MHz)
±20% (F=10MHz)
50 Ω
