ISD300- Assigning TCP/IP Parameters

TCP/IP network protocols require the storing of the IP address in the ISD so that
the device can be addressed within the network and be configured via the ISD
Control Center.
You can assign the TCP/IP parameter manually or have it assigned automatically
via DHCP (Dynamic Host Configuration Protocol). The manually assignment is
default.
Assigning TCP/IP Parameters Manually
Use the navigation keys at the front of the device to assign the TCP/IP
parameters.
Proceed as follows:
1. Press . The display shows:
IP Setup
Cancel
2. Press .
The display shows the current IP configuration ('Manual' or 'DHCP'):
IP Configuration
Manual
3. Select 'Manual' via
The display shows:
IP Address:
000.000.000.000
4. Enter the IP address.
Use to navigate to individual numerical values within the IP address.
You can change the numerical values via
5. Press to confirm. The display shows:
Netmask:
000.000.000.000
6. Enter the netmask.
7. Press to confirm. The display shows:
Gateway:
000.000.000.000
8. Enter the gateway.
Quick Installation Guide
>
<
or and press to confirm.
.
[en] 11
