First Steps

Connecting the ISD300

Proceed as follows:
1. Connect the network cable (RJ-45) to the network connector (2).
2. Connect the power cord to the power supply (8).
1234
Front view
8
Rear view
Quick Installation Guide
5 6 7
9
1) Activity LED (yellow):
The LED indicates the exchange of
network data packages.
2) Network connector (RJ-45 connector)
3) Link LED (green):
The LED indicates a (physical)
connection to the network.
4) Power LED
5) Display
6) Navigation keys
7) Soft power switch
8) Power supply/power switch
9) USB connector
