English EX-1189HMVS-2
3. Layout, Connections & Jumper Settings

3.1 Layout

1x USB 3.1 (Gen1)
Upstream B-Port
7-24V T-Block
for optional external
Power LED
Power Supply
12-24V Connector
for included external
Power Supply
7x USB 3.1 (Gen1) Status LED
Downstream A-Port for each Port
3.2 Connections
+7V - 24V T-Block:
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
GND (Ground)
+7V - 24V
