EX-1188HMS-2
3. Layout, Connections & Jumper Settings

3.1 Layout

1x USB 3.1 (Gen1)
Upstream B-Port
7x USB 3.1 (Gen1)
Downstream A-Port

3.2 Connections

12V Connector:
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
Power LED
ATTENTION!!!
Use only with Power Supply which is included in delivery!
9
English
12V Connector
for included external
Power Supply
