EX-1240HMVS
3. Layout & Connections

3.1 Layout

Front:
Back:
5V T-Block for
optional external
Power Supply

3.2 Connections

+5V T-Block:
GND (Ground)
+5V
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
2x USB 3.1 (Gen2)
Downstream A-Port
Power LED
5V Connector for
included external
Power Supply
ATTENTION!!!
Never connect power to GND, it will destroy
your Hardware!!!
Status LED
for each Port
2x USB 3.1 (Gen2)
Downstream C-Port
1x USB 3.1 (Gen2)
Upstream C-Port
9
English
