Appendix A: Technical Data

System:
• Front-end: DVB-C
• Input frequency range: UHF, VHF III, VHF I,
II, 47-862 MHz
• Powered by STi5100 CPU
• FLASH memory: 8 MB
• RAM memory: 64 MB
Connectivity:
• RF In
• RF Out for analogue TV programs
• 2x SCART
• 2x RCA (stereo audio)
• S-Video
• Optical S/PDIF digital audio output
• 1x USB 2.0
• Ethernet RJ-45
• V.92 Modem port
• Smart Card slot
• Power in
Video:
• MPEG-2 SP@ML, MP@LL, MP@ML
• Video rate: 0.5 - 15 Mbit/s, variable
• Formats: 4:3, 16:9 with Pan & Scan, Let-
terbox
• Graphics: 16 bit OSD, up to 720 x 576
pixels
Audio:
• MPEG-1 audio layer I & II
• Mono, Dual Mono, Stereo, Joint Stereo
• AC-3 pass through S/PDIF

UserInstructions
Conditional Access System:
• Support for Nagra
Software:
• OpenTV
• Loader for Over The Air software upgrades
• Teletext on VBI, DVB, OSD subtitles
• Set of applications including among other
things: channel banner, Now/Next Naviga-
tor, Parental Control, Electronic Program
Guide, PVR functionality.

Accessories:

• Remote control unit with batteries
• Set of cables
• User documentation
• Power brick (input 90-264V, 47-63Hz
output: 12V/5A)
Reliability & Compliance:
• Fully DVB compliant
• Quality according to EU norms, CE marking
• MTBF: 50 000h
General Data:
• Dimensions: 430 x 50 x 255 mm
• Five LEDs (On / Standby / RCU key
pressed, Wake, Time shift, Recording, Hard
Disk)
• Operating mode consumption: max. 30W
• Standby mode consumption: max. 10W
This specification is subject to improvement and
change without notice.
