Application of various
moulding tools
1 Rebating tasks with safety
A
moulding head " " – straight
blade – various spindle
B
bushings " " for course
setting.
Tool aligned countersunk in
table plate "C".
2 Safety moulding head "
and same tool alignment as
1 when moulding a groove.
4
Safety moulding head "
E
with profile cutters "
D
spindle ring " ".
Moulding cutter minimally
countersunk in table plate.
5 Safety moulding head "A"
with profile cutters "E"
(countersunk in table plate).
For moulding curved pieces
with bearing ring "F" aligned
in upper position
Caution!
Only work with moulding
guard "G" when moulding
fence "H" has been
removed.
6
Safety moulding head "
E
with profile cutters "
aligned in upper position
F
and bearing ring " " aligned
in lower position for
moulding curved pieces.
!
Caution
Only work with moulding
guard "G" when moulding
fence "H" has been
removed.
A
"
A
"
",
A
"
"
