Tips for working

Only perform retooling, measuring and cleaning work when the motor is turned off and the moulding
tool is at a standstill. Secure the machine from being switched on unintentionally!
Disconnect the mains plug!
Workpiece guidance, figure O
The feed direction of the workpiece always
depends on the motor direction.
When the motor direction is "forwards", the
workpiece feed direction is "right" to "left".
When the motor direction is "reverse", the workpiece
feed direction is "left" to "right".
(1) Workpiece feed direction
Pay attention to the workpiece guidance. Use aids
-
such as push handles (accessory, article no. 7963
1000) for small workpieces.
The table extension no.7324 0170 (accessory)
-
should be affixed for long workpieces.
(2) Workpiece – pushing from above
Use the push shoe to push the workpiece on to
-
the table plate from above.
(3) Workpiece – pushing from the side
As well as applying pressure from above, push
-
the workpiece against the moulding fence from
the side.
Place the push plate at the side of the workpiece.
-
Adjust guard "A" to the workpiece height.
-
(4) Moulding tool – direction
The feed direction of the workpiece (1) always
-
depends on the motor direction (4).
- The rotation direction can be changed from
"forward" to "reverse" for specific tasks using the
reversing switch.
Overhead roller guard assembly, figure P
Loosen the two clamp screws (5) by a maximum of
two turns and pull them back with the clamp flaps.
Figure O
Safety distance when using the power feed device
When using the power feed device, the distance from
the last feed roller and the wall should be at least
55cm longer than the workpiece.
The entire overhead roller guard assembly can now
be folded upwards
