Axio Observer materials
Light sources
HBO 50W/AC mercury vapor short-arc lamp
Output ....................................................................................................................................... 50 W
Average service life ................................................................................................................... 100 h
HBO 103 W/2 mercury vapor short-arc lamp .................................................................................. 100 W
Optical-mechanical data
Stand with stage focussing ............................................ with coarse focusing drive approx. 2mm/rotation
Change of objective .............................................................................................. via 6-objective revolver
Objectives ........................................................................................................... with M27 screw thread
Eyepieces ..................................................................................Plug-in diameter 30 mm, field number 23
Optical risk group classification acc. to DIN EN 62471:2009
HBO 100 ................................................................................... Risk group 2 acc. to DIN EN 62471:2009
XBO 75 ..................................................................................... Risk group 2 acc. to DIN EN 62471:2009
HXP 120 .................................................................................... Risk group 2 acc. to DIN EN 62471:2009
HAL 100 .................................................................................... Risk group 1 acc. to DIN EN 62471:2009
VIS-LED...................................................................................... Risk group 1 acc. to DIN EN 62471:2009
MicroLED ................................................................................... Risk group 1 acc. to DIN EN 62471:2009
09/2015
TECHNICAL DATA
and fine focusing drive approx. 1/10 coarse/fine focus transmission ratio,
Total travel approx. 10 mm, 13 mm also possible
431004-8044-010
ZEISS
25
