Key to Fig. 6:
1
Standby button
2 Left sideport
3 Focus drive coarse / fine (left side)
4 Control ring, left
5 Microscope stage (with inserted K mounting frame for reflected light and stage pinhole aperture)
6
Slot for iris diaphragm slider as reflected light luminous-field diaphragm (manual or motorized)
7
Slot for polarizer slider - A 6x30 mm
8 Slot for aperture diaphragm slider MAT or FL attenuator (manual or motorized)
9 Slot for 3-position filter slider, d=25 mm
10 LM set key
11
Drive knobs for controlling XY positioning of the mechanical stage
12
Right sideport
13 6-position objective nosepiece HD DIC M27 mot. ACR (motorized)
14 Compensator mount 6x20
15 Reflector turret (coded or motorized)
16 Coarse / fine focus drive (right side) with finger wheel for fine focus, flat
17
Control ring, right
18 TFT display
19 RL button for switching the LED / halogen light or the reflected light shutter (fluorescence) on and off
20 Knurled wheel for LED light / halogen illuminator intensity control
21 Frontport
22
Binocular tube
23
Binocular section of the binocular tube
24 Eyepiece
25 Eyepiece adjustment ring
A full description of operation is provided in the operating manual of the Axio Observer
431004-7144-001.
