5

Shipping conditions

Pull out the power plug before transport.
Fig. 15 Transporting the Axio Observer
Full transportation descriptions are provided in the operating manual of the Axio Observer
431004-7144-001.
All Axio Observer models may only be transported individually across a few meters using the
mounted transport handles (Fig. 15/3). For transporting over long distances the device must be
partially dismantled and wrapped in the original packaging.
Following transportation, the device should be reassembled in the reverse order.
22
SHIPPING CONDITIONS
•
Switch off the Axio Observer (Fig. 15/1).
•
Disconnect the device from the mains voltage
by removing the power cable (Fig. 15/2) from
the Axio Observer.
•
Remove the transmitted
microscope stage and binocular tube,
•
Screw on the transport handles (Fig. 15/3) using
a 4 mm Allen key.
431004-8044-010
Axio Observer materials
light illuminator,
09/2015
