Optional Equipment; Wearing Parts - Lagler SUPERHUMMEL Betriebsanleitung

• 1 Hexagonal socket screw wrench size 4 mm
• 1 Hexagonal socket screw wrench size 5 mm
• 1 Hexagonal socket screw wrench size 6 mm
• 1 Box wrench
• 1 Setting fixture
• 1 Short lower rod
• 1 Respiratory protection mask P3
• 1 Safety belt

1.5.2 OPTIONAL EQUIPMENT

• TransCart
• Foldable earmuff

1.5.3 WEARING PARTS

Check the state of the following wearing parts on a regular basis to ensure a consistent quality and efficiency of
your work.
Replace after wearing or damage:
• Extension cable
• Motor cable
• O-ring used as a strain relief device
• On/Off switch
• Sealing felt
• Dust bag
• MultiClip for dust bag fixture
• V-belts
• V-belt pulleys
• Belt tensioner
• Sanding drum (after daily use exchange every 1-2 years)
• Tensioning roller (after daily use exchange every 1-2 years)
• Guide roller of the drive unit
• Side cover
• Rear wheel
• Lateral wheels
