Loading the feed screw.
Should the pellet hopper empty completely the feed
screw must be filled. To do so, keep the + and – keys
pressed simultaneously for a few seconds (on the remote
control or synoptic panel). Once released, 'REFILL' will
appear on the display.
This must be carried out before ignition if the stove has
stopped due to the pellets having finished.
It is quite normal for some pellet residue to remain inside
the hopper, this is what the feed screw is unable to pick
up.
Once a month, fully vacuum the hopper to prevent dusty
residue from accumulating.
Automatic ignition
With the stove on standby, press the 0/1 button for 2
seconds (on the synoptic panel or remote control). This
will startup the ignition process, 'Start' will appear on the
display and a countdown will commence in seconds
(1020). There is no preset time for the ignition process:
its duration will be automatically shortened if the control
board detects that certain tests have been carried out
positively. The flame appears after about 5 minutes.
Manual ignition
Insert a well-lit firelighter into the combustion chamber,
close the door and press 0/1 on the synoptic panel or
remote control.
Operating modes
Manual: the user sets the desired operating power
(3 ventilated power levels and 3 non-ventilated power
levels).
Automatic: the user sets the temperature desired in the
room. The stove reads this and adjusts the power to reach
the set temperature. Once this is reached, it sets itself to
power 1.
Manual mode from synoptic panel/remote control
(optional)
With the stove in operation mode or on standby, press
and release the MENU button on the synoptic
panel/remote
control and 'Power' will appear on the display (showing
the power at which the stove is working). Press the + key
on the remote control to increase the operating power
(from Power 1 to Power 5).
INSTRUCTIONS FOR USE
Automatic mode from synoptic panel/remote control
Press the MENU button twice to switch from manual to
automatic mode and adjust the temperature desired for the
room (use the + and – keys on the remote control to set
the temperature between 10 and 29 ...., and the stove will
regulate the operating power required to reach it.
If the set temperature is lower than the room temperature,
the stove works at Power 1.
Shutdown
For greater comfort, the stove and the air vents go off
at the same power at which it was operating.
With the stove in operation mode press the 0/1 key for 2
seconds (on the synoptic panel or remote control). The
shutdown procedure will begin and the countdown is
displayed. This varies according to the power at which it
is running when the shutdown phase begins.
The shutdown phase (which will extinguish the flame
without leaving any unburnt material in the combustion
chamber and cool the stove), consists of:
• Pellet loading ceases.
• Ventilation is activated at the level at which the stove
was operating.
• Smoke expulsion motor enabled.
Never unplug the stove during the shutdown process.
Setting the clock
Press the MENU button for 2 seconds and use the + and –
keys to follow the instructions given on the display to
access the 'Clock' menu.
This allows you to set the time on the electronic control
board.
Then press MENU and the following data appears in
sequence – this can be adjusted:
day, month, year, hour, minutes, day of the week.
When 'Save?' appears on the display you can check that
the settings have been entered correctly before confirming.
Press MENU to save the information ('Save OK' then
appears on the display).
