MIMIC PANEL
hold down for 2 seconds to turn stove on or off
opens the menu
increases/decreases the various settings
(pellet load/reserve key) pressed once it tells the stove that a 15 kg. sack of pellets has been loaded,
enabling the reserve to be monitored (see following page 31)
The RIGHT DISPLAY shows the level of ventilation and channelling.
The LEFT DISPLAY shows the level of power or temperature and reserve or time and date.
to activate/deactivate ventilation
LH Display
POSSIBLE VIEWS
STAND-BY
INSTRUCTIONS FOR USE
Pellet load / reserve
DATE
TIME
RESERVE
Ventilation
activation/exclusion
RH Display
MANUAL
POWER
AIR OFF
VENTILATION
- - - - - - - - - -
AUTOMATIC
TEMPERATURE
COMFORT AIR
VENTILATON
- - - - - - - - - -
29
EXCLUSION
ROOM
ACTIVATED
