Before igniting.
You must consult the Edilkamin DEALER in your area
when igniting the stove for the first time, in order for the
stove to be calibrated according to the type of pellets and
installation conditions, thereby validating the warranty.
There may be a slight smell of paint the first few times it is
ignited, however, this will disappear quickly.
Before igniting you must check:
==> that installation is correct
==> the power supply
==> that the door closes properly to a perfect seal
(inner righthand door).
==> that the combustion chamber is clean
==> that the display is on standby (the date, power or
temperature flashes).
Filling the pellet hopper
To access the tank, open the two small doors on the rear of
the cast top* (fig. 1-2).
N.B.:
1) DURING THIS OPERATION, NEVER PLACE
THE BAG OF PELLETS ON THE TOP GRILLE, AS
THE HEATED PLASTIC BAG CAN DAMAGE THE
PAINT OF THE TOP.
2) Use the glove supplied when filling the stove whilst it is
running and therefore is hot.
NOTE regarding the fuel.
FORMA - TWIN
is designed and programmed to burn wood pellets with 6 mm diameter.
Pellets are a type of fuel in the form of little cylinders, made from
compacted sawdust, compressed under high pressure with no adhesives or foreign materials. They are sold in bags of 15 kg.
For the stove to function properly, you MUST NOT burn anything else in it. Using other materials (including wood) will render
the warranty null and void. Such use is detected by laboratory analyses.
Edilkamin has designed, tested and programmed their stoves to guarantee the best performance when pellets with the following
characteristics are used:
diameter: 6 millimetres - maximum length: 40 mm - maximum moisture content: 8% - calorific value: at least 4300 kcal/kg.
If pellets with different characteristics are used, the stoves must be recalibrated – a similar procedure to that carried out by the
DEALER when the stove is ignited the first time.
Using unsuitable pellets may: decrease efficiency; cause malfunctions; stop the stove from functioning due to clogging, dirt on the
glass, unburnt fuel, etc.
A simple, visual analysis of the pellets may be carried out:
Good quality: smooth, uniform length, not very dusty.
Poor quality: with longitudinal and transverse cracks, very dusty, various lengths and mixed with foreign matter.
INSTRUCTIONS FOR USE
Fig. 1
Fig. 2
