1. Quick Guide
[Auto on]: The frequency converter is controlled either via control terminals or serial communication.
[Potentiometer] (LCP12):
1
In Auto Mode the potentiometer acts as an extra programmable analog input.
In Hand on Mode the potentiometer controls local reference.
▲ ▼
Arrows [ ] and [ ] toggles between the choices in each menu.
The display indicates the status mode with a small arrow above "Status".
The Quick Menu gives easy access to the most frequently used parameters.
1. To enter the Quick Menu, press [MENU] key until indicator in display is placed above
▲ ▼
2.
Use [ ] [ ] to select either QM1 or QM2, then press [OK].
▲ ▼
3.
Use [ ] [ ] to browse through the parameters in the Quick Menu.
4. Press [OK] to select a parameter.
▲ ▼
5.
Use [ ] [ ] to change the value of a parameter setting.
6. Press [OK] to accept the change.
7. To exit, press either [Back] twice to enter
No Name
1-20 Motor Power [kW]/[HP]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor nominal speed
1-29 Automatic Motor
(AMT)
3-02 Minimum reference
3-03 Maximum reference
3-41 Ramp up time 1
3-42 Ramp down time 1
Table 1.5: Basic Settings Quick Menu 1
The Main Menu gives access to all parameters.
1. To enter the Main Menu, press [MENU] key until indicator in display is placed above
▲ ▼
2.
Use [ ] [ ] to browse through the parameter groups.
3. Press [OK] to select a parameter group.
▲ ▼
4.
Use [ ] [ ] to browse through the parameters in the specific group.
5. Press [OK] to select the parameter.
▲ ▼
6.
Use [ ] [ ] to set/change the parameter value.
7. Press [OK] to accept the value.
8. To exit, press either [Back] twice to enter
8
The potentiometer works in two ways depending on the mode in which the frequency converter is running.
Status
, or press [Menu] once to enter
Range
[0.09kW/0.12HP - 11kW/15HP] Unit dependant Enter motor power from nameplate data
[50 - 999V]
[20 - 400 Hz]
[0.01 - 26.00 A]
[100 - 9999 RPM]
Tuning [0] = off
[2] = Enable AMT
[-4999 - 4999]
[-4999 - 4999]
[0.05 - 3600s]
[0.05 - 3600s]
Quick Menu
, or press [Menu] once to enter
MG.02.B4.83 - VLT
Quick Menu .
Main Menu
.
Default Function
230/400 Enter motor voltage from nameplate data
50 Enter motor frequency form nameplate data
Unit dependant Enter motor current from nameplate data
Unit dependant Enter motor nominal speed from nameplate data
[0] = off Use AMT to optimize motor performance.
1. Stop VLT
2. Choose [2]
3. "Hand On"
0 Enter value for minimum reference
50.00 Enter value for maximum reference
3.00 Ramp up time from 0 to rated motor frequency par. 1-23
3.00 Ramp down time form rated motor frequency par. 1-23 to 0
Main Menu
.
Status
.
®
is a registered Danfoss trademark
Quick Guide for VLT Micro FC 51
