1. Quick Guide
Temperature during storage/transport
Maximum altitude above sea level without derating
1
Maximum altitude above sea level with derating
Derating for high altitude, see section on special conditions
EMC standards, Emission
EMC standards, Immunity
See section on special conditions
1.1.23. Derating for Ambient Temperature
The ambient temperature measured over 24 hours should be at least 5 °C lower than the max. ambient temperature.
If the frequency converter is operated at high ambient temperature, the continuous output current should be decreased.
The frequency converter has been designed for operation at max 50 °C ambient temperature with one motor size smaller than nominal. Continuous
operation at full load at 50 °C ambient temperature will reduce the lifetime of the frequency converter.
1.1.24. Derating for Low Air Pressure
The cooling capability of air is decreased at low air pressure.
For altitudes above 2000 m, please contact Danfoss regarding PELV.
Below 1000 m altitude no de-rating is necessary but above 1000 m the ambient temperature or the maximum output current should be decreased.
Decrease the output by 1% per 100 m altitude above 1000 m or reduce the max. ambient temperature by 1 degree per 200 m
1.1.25. Derating for Running at Low Speeds
When a motor is connected to at frequency converter, it is necessary to check that the cooling of the motor is adequate.
A problem may occur at low speeds in constant torque applications. Running continuously at low speeds – below half the nominal motor speed – may
require additional air cooling. Alternatively, choose a larger motor (one size up).
1.1.26. Options for VLT Micro Drive
Ordering No
132B0100
132B0101
132B0102
132B0103
132B0104
132B0105
132B0106
132B0107
132B0108
132B0109
132B0110
132B0111
Danfoss Line Filters and brake resistors are available upon request.
18
Description
VLT Control Panel LCP 11 w/o potentiometer
VLT Control Panel LCP 12 with potentiometer
Remote Mounting Kit for LCP incl. 3 m cable IP55 with LCP 11, IP21 with LCP 12
Nema Type 1 kit for M1 frame
Nema Type 1 kit for M2 frame
Nema Type 1 kit for M3 frame
De-coupling plate kit for M1 and M2 frames
De-coupling plate kit for M3 frame
IP21 for M1 frame
IP21 for M2 frame
IP21 for M3 frame
DIN rail mounting kit for M1 frame
®
MG.02.B4.83 - VLT is a registered Danfoss trademark
Quick Guide for VLT Micro FC 51
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EN 61800-3, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3,
EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
-25 - +65/70 °C
1000 m
3000 m
