ENGLISH
APPLICATION
The Evo-Multimax pump is a horizontal
self-priming multi-stage pump for pump-
ing clean liquids without solid suspended
particles, fibers, or abrasive materials
that may chemically or mechanically at-
tack the pump, or liquids not compatible
with the pump construction material.
The pump can be used to pump water in:
• water distribution systems
• irrigation systems
• rain water collection systems
Never use the pump for flamma-
ble and/or explosive liquids.
Improper use of the pump can
lead to physical injury and/or
material damage. Improper use
of the product will render the warranty
null and void.
Note
The pump is designed for use with drink-
ing water destined for human use (ACS).
Application Limits
• Temperature of pumped liquid: from
+5°C to +50°C in compatibility with the
pump materials.
• Maximum ambient temperature:
+40°C;
• Max. operating pressure: 8bar
(0.8MPa);
the data plate (Figure 5) lists the specifi-
cations:
Pos. Description
1 Type of pump
2 Flow rate range
3 Head range
16 16
4 Minimum head
5 Number of phases
6 Voltage
7 Frequency
8 Motor rpm
9 Insulation class
Absorbed power of electric
10
pump
11 Rated current
12 Condenser capacity
13 Protection rating
14 Maximum liquid temperature
15 Serial number
16 Date of manufacture
Sound pressure level
The sound pressure level is below 70dB
(LpA) on the following models:
Evo-Multimax 340 Logic Safe, Evo-mul-
timax 340 Kit,Evo-Multimax
Safe, Evo-Multimax 840
Maximum head
See appendix. A1
Transport and storage
On delivery, check that the electric pump
has not been subject to damage during
transport; in this case notify the retailer
immediately.
Check procedure phases:
• check the exterior of the packaging;
• remove all product packaging mate-
rial;
• inspect the product for possible dam-
aged parts;
• contact the retailer if any defects are
found.
