6. Connection and Operating Elements
(41) VINYL button
Press this button in order to activate the scratch function of the jog wheel (43). The button is lit up in blue.
(42) PLAY/PAUSE button
Press this button in order to start or stop playback.
(43) Jog wheel
The jog wheel allows you to create scratch effects, to fast-forward or rewind within a track and to modify the playback speed.
If you have already pressed the VINYL (41) button (button is lit up in blue), you can create scratch effects in pause and playback mode by
moving the jog wheel forwards and backwards. Turn the jog wheel clockwise to fast-forward within the track. Turn the jog wheel anti-clockwise
to rewind within the track. The faster you turn the jog wheel, the faster the track will skip forwards/backwards.
If the VINYL button is not activated (button is not lit up), you can use the jog wheel in pause mode to fast-forward or rewind the track. In
playback mode you can modify the playback speed. Rotate the jog wheel clockwise to increase the speed. Rotate the jog wheel anti-clockwise
to decrease the speed.
(44) Channel fader
Using these slide controls, you can set the levels of the individual channels. The maximum level is achieved in the control position "10", the
minimum level in position "0". One fader is available per channel.
(45) LED level indicator
The level indicator provides information about the signal level (MASTER output level). The value shown on the display should not exceed the
"0 dB" value in order to prevent distortion of the music signal.
(46) Cross fader control
This slider is used to cross-fade between the channels CH1 and CH2, i.e. one channel is faded out (becomes quieter) while the other channel
is faded in (becomes louder).
When the cross fader is in the middle position, the channels CH1 and CH2 are played at the same volume.
(47) TAP button
Press the TAP button repeatedly to the beat of the music in order to manually define the BPM (beats per minute). The value is shown on the
display.
The control elements (25) through (43) plus (47) only work if the track is being played back from a USB device or SD card.

7. Installing the device

When setting the device up or installing it in a desk make sure to pay attention to sufficient ventilation.
Do not place the device on soft surfaces, such as a carpet or a bed etc.
Moreover, the air circulation must not be obstructed by such objects as magazines, table cloths or the like. This stops
the heat dissipation of the product and can lead to overheating (fire hazard).
Do not drill any holes in the mixing desk case. The device may otherwise be damaged and this could impair its safety.
When setting up the device, it is important to pay attention to a secure position and a firm surface.
A fall of the mixing desk could injure people.
During set up or installation of the device, make sure the connecting cables are neither jammed nor damaged by sharp
edges.
Only place cables in a way so that nobody could fall over them or get caught by them. Risk of injury.
When selecting a location, make sure it is not exposed to direct, intensive sunlight, vibrations, dust, heat, cold or humidity.
No devices with strong electric or magnetic fields such as transformers, motors, cordless phones, radio devices etc.
must be in the direct proximity of the mixing desk, since they may interfere with the mixing desk.
Place the device securely on an even surface. Never place the device on valuable or delicate furniture without suitable
protection.
23
