SPARE PARTS LIST FBH-1100K
FERM NR
DESCRIPTION
700171
DEPTH GAUGE
700172
SIDE HANDLE
700393
LOCKING SLEEVE (SET)
806001
BEARING 6001 ZZ
700394
ROTOR
700395
STATOR
700396
CARBON BRUSH (SET)
700397
SWITCH
800608
BEARING 608 ZZ
54
REF NR
24
ROTARY HAMMER DRILL
25 TILL 29
76 TILL 78
THE NUMBERS IN THE TEXT BELOW
81
CORRESPOND TO THE ILLUSTRATIONS ON
PAGE 2
82
89
TECHNICAL SPECIFICATIONS
95
107
Voltage
Frequency
116
Power rating
Rotational speed,not loaded | 750/min
Impact rate
Max.drill capacity
concrete
steel
wood
Weight
Lpa (sound pressure level)
Lwa (sound power level)
Vibration value
PRODUCT INFORMATION
Fig.A+D
1. Rotary stop selection lever
2. On-off Switch
3. Main handle
4. Hammer stop selection lever
5. Carbon brush cap
6. Electric cord
7. Auxiliary handle
8. Depth gauge
9. Dust cap
10. Drill
11. Locking sleeve
INTENDED USE
The Ferm FBH-1100K is intended for drilling holes in
masonry such as brick,concrete and similar materials.
Furthermore,the machine can be used as a demolition
hammer in combination with the SDS cold chisels
provided.The machine is on no account intended for
other purposes.
Please inspect the machine and accessories for transit
damage.
Ferm
Ferm
SAFETY INSTRUCTIONS
In this operator's guide the following symbols are used:
Indicates hazard of bodily injury,fatality or damage
to the machine,if the instructions in this operator's
guide are not followed.
Indicates electrical shock hazard.
Read this manual carefully,before using the machine.
Ensure that you know how the machine works,and how
it should be operated.Maintain the machine in
| 230 V
accordance with the instructions,and make certain that
| 50 Hz
the machine functions correctly.Store this manual and
| 1100 W
other enclosed documentation with the machine.
| 2920/min
SPECIFIC SAFETY INSTRUCTIONS
|
| Ø 30 mm
FOR USE OF THIS MACHINE TOOL
| Ø 16 mm
•
Inspect the surface to be drilled for hidden electrical
| Ø 40 mm
wiring,gas pipes or other obstacles (for example,
| 6.0 kg
using a metal detector).
| 90.7 dB(A)
•
Check the following points:
| 101.7 dB(A)
Does the appliance's voltage correspond with the
| 4.3 m/s
2
mains power supply voltage?
Are power cords,insulation and plug in good order:
sound,not loose or damaged?
Is there a good,firm connection at the mains socket?
Does the drill show any sign of abnormal running,
overheating or excessive sparking?
Whenever any of the problems mentioned above
appear,immediately cease using the machine and
have it repaired by an expert.
ELECTRICAL SAFETY
Caution! Whenever working with electric tools,basic
safety precautions must be taken to reduce the risk
of fire,electric shock,and personal injury.Read all
the instructions before you begin operating this
machine,and keep them in a safe place.
Always check that the mains voltage is the same as
on the type plate of the machine.
The machine is double insulated compliant with
EN50144;therefore,no earth connection is
required.
Replacement of power cords or plugs
Immediately dispose of old cords and plugs once they
have been replaced.It is dangerous to plug a loose power
cord into a mains power socket.
Use of extension leads
Only ever use approved extension leads that are suitable
for the power rating of the machine.The minimum core
thickness is 1.5 mm
lead,always fully unroll the lead.
2
.Whenever using a reel extension
