SPARE PARTS LIST FTB-13
REF NR DESCRIPTION
27 MOTOR
37 MAGNETIC SWITCH
50 COVER FOR SPRING
51 SPRING
56 CHUCK GUARD
58 V-BELT
10 CHUCK
- CHUCK KEY
- CONDENSER
62
FERM NR
311053
BENCH PILLAR DRILL
311051
311059
THE NUMBERS IN THE FOLLOWING TEXT
311058 CORRESPOND WITH THE PICTURES AT PAGE 2
311055
TECHNICAL SPECIFICATIONS
800157
311054
Voltage
Frequency
311057
Power input
311056
No load speed
Number of speeds
Chuck capacity/Morse Conical
Weight
Lpa (sound pressure level)
Lwa (sound power level)
Vibration value
PRODUCT INFORMATION
Fig.A
1. On/off switch
2. Drill depth gauge
3. Protection guard
4. Motor
5. Drill depth lever
6. Table adjustment
Check first whether or not the delivery has been
damaged by transport and/or whether all the parts are
present.

SAFETY INSTRUCTIONS

The following pictograms are used in these instructions
for use:
the instructions in this manual.
Carefully read this manual before using the machine.
Make sure that you know how the machine functions and
how to operate it. Maintain the machine in accordance
with the instructions to make sure it functions properly.
Keep this manual and the enclosed documentation with
the machine.
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions. Keep these
instructions in a safe place!
Ferm Ferm
| 230 V
| 50 Hz
| 350 W
| 580-2650/min
| 5
| 13mm/ B-16
| 20 kg
| 62.1 dB(A)
| 75.1 dB(A)
| 1.57 m/s 2
Denotes risk of personal injury, loss of life or
damage to the tool in case of non-observance of
Denotes risk of electric shock.
Before using the machine the guidelines must be taken
into consideration. Every mechanical or electrical
alteration to the machine which does not meet the
applicable guidelines carries a considerable accident risk.
DURING USE THE FOLLOWING POINTS
MUST BE CONSIDERED:
• Do not remove any mechanical or electrical
protective provisions.
• Check whether all the protective provisions are in
place and have been attached correctly.
• Wear safety goggles during drilling.
• If you have long hair, be sure to wear hair protection
(hair net or cap). Long hair can easily be caught in
moving parts.
• Wear fitted clothing; tie buttons on sleeves.
• Do not hold any workpieces in your hands when
drilling. Always use a machine clamp or another
clamping tool.
• Protect workpieces and clamping tools on the bench
to prevent them from getting caught. Fasten them
yourself with screws or clamp them to a machine
clamp fastened to the table.
• Check whether the drill holder is tightened properly.
• Check whether cable lead-throughs are okay.
• To remove drill chips only use hand brushes,
brushes, rubber wipers, chip hooks or similar aids.
• Do not carry out any cleaning or greasing work while
the machine is in operation.
• Always keep V-belts covered (so that your hands
cannot become caught).
• Only tighten the toothed ring drill holder by means
of the wrench.
• Never leave the wrench of the drill holder in the drill
holder! Before switching on the machine, check
whether the wrench really has been removed!
• Do not use any drills which are damaged on the
shank.
• Drill is not suitable to use as press!
• If the mains cable is damaged, it may only be replaced
by a mains cable of the same type.
IMMEDIATELY SWITCH OFF THE MACHINE
WHEN:
• Interruption in the mains plug, mains lead or mains
lead damage.
• Defect switch.
• Smoke or stench of scorched isolation.
ELECTRICAL INSTALLATION
The machine is provided with an electrical installation,
which meets the standards. Repairs may only be carried
out by a recognised professional.
The machine is provided with a zero voltage switch.
After the tension drops the machine will not start to
run automatically for safety reasons. The machine must be
switched on again.
ELECTRICAL SAFETY
Always check that the power supply corresponds to the
voltage on the rating plate.
3
