FRONT
OPEN ClOSE
OPEN
6
!
FRONT
OPEN ClOSE
OPEN
English
NOTE:
To return the shield to fully closed position,
the shield latch tab must be pushed back. It
is not sufficient to push the shield itself down.
Re-closure must be made by means of the shield
latch tab.
TO OPERATE BROWVENTS
The Browvents are operated from fully closed
through intermediate, to fully open positions by
simply pulling the vent control down to open,
pushing up to close.
TO OPERATE MOUTHVENT
The Mouthvent is operated by simply pulling the
vent control down to open, pushing up to close.
When the vent control is fully open, air is directed
up along the interior surface of the shield to help
prevent fogging and when it is in its mid-way
position air is channelled back to further enhance
the airflow around the mouth and nose to help
move hot moist air out faster.
TO OPERATE TOP VENTS
Simply push the switches/levers on each vent to
open/close the vents.
