TO REMOVE/REPlACE CHEEKPADS
When first servicing the cheekpads, it is suggested
that you do only one at a time so that the other can
be used as a reinstallation guide.
To remove the cheekpads, first undo chinstrap. Lift
up the neckroll tab, which is inserted under the
black covering at the forward lower edge of the pad
assembly.
RX-7GP / CORSAIR-V / QUANTUM / RX-Q
Pull the pad toward the rear of the helmet, then
inward to release and slide it off the strap.
CHASER-V / VECTOR-2
Pull the pad toward the front of the helmet, then
inward to release and slide it off the strap.
To take off the fabric covering for washing, peel
the covering off over the rear edge of the cheekpad
assembly until all the fabric is on the face side
surface. Then draw the covering through the
opening by grasping the rectangular collar and
pulling.
To wash fabric coverings, put them into lukewarm
water with small amount of laundry soap or your
own shampoo and wash gently by hand. Rinse well
with fresh water and wipe off with a soft cloth. Dry
them in the shade at ambient temperature.
WARNING:
Never use petrol, thinner, benzene or any other
solvents.
To replace the fabric covering, ensure it is turned
right side out, and stretch the covering over the pad,
and adjust the covering to lie smoothly. Then push
the rectangular collar through the pad assembly and
adjust into final position.
