TO REMOVE/REPlACE BASE PlATES
To remove base plates, remove shield and holders,
remove the two screws from each plate with a flat
blade screwdriver or a coin. Remove plates from
helmet shell.
To replace the base plates, with the parts off the
helmet, align the shield on the base plates as if the
shield was in the fully open position, then rotate
the shield downward in relationship to the base
plates to the equivalent of the fully closed position
ensuring that the white spring clip section of the
plate is fully home in the sliding slot of the shield.
Position the shield/base plates assembly on the
helmet to approximate the shield in fully closed
position. The plates' screw holes will be over the
threaded screw receptacles in the helmet. Install the
two screws through each base plate into the helmet
leaving them slightly snug, but not fully tightened.
Push on the front of the shield to bring it fully home
against the eyeport trim. While still pushing on
the shield to keep it tight against the helmet, fully
tighten the base plate screws. It may be necessary
to do one side at a time, with a "smoothing"
pressure from the shield centre toward each base
plate and tightening each in turn for best results.
Move the shield to fully open position and remove
it. The holders cannot be properly reinstalled if the
shield is left in place. Reinstall the holders, then,
reinstall the shield as per previous instructions.
