Task 2: Mounting VessJBOD in a Rack

The VessJBOD subsystem installs to the rack using the available mounting rails.
You can also use your existing rails.
Figure 4. VessJBOD mounted in a rack with the available rails
Vertical Rack Post
Handles mount
outside the rack post
To install the VessJBOD subsystem into a rack with the available mounting rails:
1. Check the fit of the mounting rails in your rack system.
2. Adjust the length of the mounting rails as needed.
• At least two persons are required to safely lift, place, and
attach the VessJBOD subsystem into a rack system.
• Do not lift or move the VessJBOD subsystem by the handles,
power supply or the I/O module. Hold the subsystem itself.
• Only a qualified electrician who is familiar with the installation
procedure should mount and install the VessJBOD
subsystem.
• Be sure all switches are OFF before installing the VessJBOD
subsystem or exchanging components.
Task 2: Mounting VessJBOD in a Rack
VessJBOD subsystem
Mounting rails mount
outside the rack post
Cautions
