Emptying The Dust Bin; Cleaning The Dust Fi Lter - Cleanmaxx Z 09270 Gebrauchsanleitung

• If needed, clean the housing with a damp, soft cloth. Then dry it with a soft cloth.
• Regularly remove hairs and lint from the nozzles.
The fi lters may discolour over time. This is normal and also does not affect
functionality.

Emptying the dust bin

1. Remove the suction hose from the dust bin (see chapter "Assembly", section "Inser-
ting/removing the hose").
Cleaning the dust fi lter
The dust fi lter is located in the dust bin.
1. Remove the suction hose from the dust bin (see chapter "Assembly", section "Inser-
ting/removing the hose").
2. Push the release button on the dust bin and pull it out of the device by the handle.
2. Push the release button on the dust bin and pull it out of
the device by the handle.
3. Hold the dust bin over an open garbage bin. The dust bin
should be as close as possible to the garbage bin so that
dust from the dust bin only falls into the garbage bin and
is not dispersed in the surrounding area.
4. Push the button to open the dust bin. The bottom of the
dust bin will open and the dirt will fall out.
5. Shut the bottom of the dust bin again. The fastener must
audibly lock into place.
6. Insert the dust bin in the device: Take hold of it by the
handle and insert the bottom of the bin in the device fi rst.
Then push the handle against the device housing until the
dust bin audibly locks into place. Hold the device by the
handle and lift it to check whether the dust bin is properly
seated.
3. Turn the dust bin cover to remove it. NOTE: Orientation
marks for the removal and placement of the cover are pro-
vided on the cover and dust bin. You can remove the co-
ver when the mark on the dust bin is pointing towards the
open lock symbol on the cover.
4. Pull the dust bin cover with the dust fi lter out.
27
