Startup
Burner adjustment data
Type
G 04.430 DUO
The above adjustment data correspond to the default settings. Pre-delivery adjustment settings appear within a black
rectangle. These settings allow the burner to be run in normal operation, but always carry out a careful check of adjustment
34
Burner power
st
nd
1
Stage
2
Stage
150
250
180
300
210
350
240
400
260
430
Adjusting the gas pressure switch
· Remove the cover of the gas
pressure switch.
· Provisionally adjust gas pressure
switch to minimum setting.
Adjusting the air pressure switch
· Remove transparent cover.
· Provisionally adjust air pressure
switch to minimum setting.
03/2005 - Art. Nr. 13 018 082A
Dimension
Y
st
1
Stage
(mm)
Cam
20
17
30
17
30
20
40
25
40
27
Air-flap opening
nd
2
Stage
IV
Cam
I
25
30
35
40
45
