Header  The header shows the title of the current menu.
List field  The list field shows the menu items of the selected menu.
there are two types of menu items:
 Menu items with submenus:
These items are displayed with three dots (...) in the right col-
umn. Select these items with the
open the submenu.
 Menu items without submenus:
The current setting is shown behind the menü item and can be
changed directly.
Footer 
The footer shows the most important keys to operate the cur-
rently displayed menu and further information if available.

Operating the on-screen display

The on-screen display is operated with the console keyboard. The following table
shows you a list of frequently used keys:
Arrow keys: Press the arrow keys
Right
Enter:
Use this key to confirm inputs of open a submenu.
Esc:
This key closes the displayed menu and shows the superior
menu.
A message is shown if entries are changed but not saved.
Tab key: Use this key to move the cursor within the list field from one
menu item to the next (or vice versa).
F2:
Press this key to save your settings.
The displayed menu closes after the settings are saved and the
superior menu is displayed again.
F8:
Press this key to switch between the different options of a menu
item.
Ctrl+F8: Configuration settings with many options support this hotkey
to open a clearly-arranged list containing all options.
and
Up
) to move the cursor between the different menu items.
and press
arrow keys
(in some menus also
Down
G&D DP-Vision-CAT · 21
Configuration
to
Enter
and
Left
