Installation
Connecting the computer's video output
USB 2.0 CPU
DisplayPort CPU: Use the DP-Cable-M/M-2 cable to connect the computer's video out-
put to this interface.
NOTE: One
DisplayPort CPU
nel variants. The number behind the name of the interface assign each interface to
a particular channel.
Connecting audio and RS232 interfaces
USB 2.0 CPU
Use an Audio-M/M-2 audio connection cable to connect the omputer's Line-
Line In:
Out interface to this interface
Use an Audio-M/M-2 audio connection cable to connect the omputer's Line-
Line Out:
In interface to this interface.
RS232: Use the RS232-M/F-2 cable to connect one of the computer's 9-pin serial
interfaces to this interface.
Connecting further interfaces of ARU2 variants
USB 2.0 CPU
USB 2.0 CPU: Use the USB-AM/BM-2 cable to connect one of the computer's USB
interfaces to this interface.
USB 2.0 Trans. Plug a category 5e (or better) twisted pair cable, which is available as
accessory, into this interface. Connect the other end of the cable to the
interface of the user module.
6 · G&D DP-Vision-CAT
USB 2.0 Trans.
In Line
DisplayPort 1
Transmission CPU
interface is available for every video channel of multi-chan-
USB 2.0 Trans.
In Line
Transmission DisplayPort 1
CPU
USB 2.0 Trans.
In Line
Transmission CPU DisplayPort 1
RS232
Out Keyb./Mouse
Keyb. CPU Mouse USB CPU
Out
RS232
Keyb./Mouse
Out
Keyb. CPU Mouse USB CPU
Out
RS232
Keyb./Mouse
Out
Out Keyb. CPU Mouse USB CPU
Red. Power
Red. Power
Red. Power
USB 2.0 Trans.
