Type 2000, 2002, 2012
2030, 2031, 2032, 2033

Option: Electrical position repeater

10. oPTIon: elecTrIcal
PoSITIon rePeaTer
with optical position display
10.1. actuators d-50 bis f-80
Fig. 10: Actuators D-50 to F-80 with electrical position repeater
Parts required
1 Electrical position repeater
with appliance socket
2 Adapter
10.1.1. Work to be carried out before
installation
DAnger!
hazard due to high pressure!
• Interrupt the control air and fluid infeed before modifying the
devices and reduce the pressure in the fluid system.
→
Interrupt supplies of control air and medium
→
Unscrew transparent cap
→
Screw out position indicator with Allan key (
10.1.2. Installation and commissioning
→
② (see "Fig. 10: ") instead of transparent cap
Screw adapter
onto actuator
→
Screw electrical position repeater
adapter ②.
english
.
from actuator cover.
WAF5).
① (see "Fig. 10: ") into
23
