„PEN REMOTE" (Pentax) or
„SAM REMOTE" (Samsung) or
„SON REMOTE" (Sony)
• Press the button, thus the selected
OK
remote mode is set, in the example
"OLY REMOTE" (Olympus). The ratio
of the reflectors is 1:1. Group A (only
with CAN, NIK and OLY) is automati-
cally set if another group has not been
selected for a previous application.
• If the two reflectors should be set at
an unequal ratio (Ratio) then press
the button or to change the
ratio of both the reflectors.
The setting thus made will be automa-
tically saved.
In the operating modes
"CAN REMOTE" or "NIK REMOTE"
and/or "OLY REMOTE", various slave
channels and various slave groups can
be set when several slave flash units
are used (see Chapter 4.2).
In the operating modes
"PEN REMOTE" and/or
"SAM REMOTE" and/or
"SON REMOTE", only different slave
channels can be set when several
slave flash units are used (see
Chapter 4.2 and operating manual
of the camera). The flash unit sup-
ports the wireless Sony remote
system in the "CTRL" and "CTRL "
modes, depending on the camera
GrA
OLY
system used. The "CTRL" and "CTRL
1:1
" modes are automatically detected.
The slave flash units always work in
the "RMT" group. The set-up can
always be checked by pressing the
"AEL" key on the camera. The slave
flash unit must respond with a time-
GrA
OLY
delayed flash.
8:1
4.2 Setting remote channel and
remote group
Four independent remote channels
(CHANNELS 1 to 4) are available, so
that several remote systems in the
same space does not cause mutual
disruption Master and/or controller
and slave flash units that belong to the
same remote system must be set to the
same remote channel.
In the case of Sony and Pentax
cameras "CHANNEL ALL" must be
+
+
75
