inwards by 10°, at the second posi-
tion by 20°.
The working distance is the distance
between the object and the front
edge of the flash unit.
As a guideline, we recommend :
• Working distance of approx.
2-10cm: Swivel reflectors by 20°
and set the bounce diffuser (see 9.1)
in front of reflectors.
At distances over 10 cm, the reflectors
can be swivelled to a greater or lesser
extent to achieve a centre weighted
average or a balanced illumination.

9.1 Bounce diffuser

The bounce diffuser
illuminating the objects in close proxi-
mity at distances less than 10 cm.
Installation of bounce diffuser
Position the bounce diffuser
metrically over the flash unit so that
the reflectors
light are covered.
Press the bounce diffuser
the housing of the flash unit until it
82
is required for
asym-
and the AF auxiliary
against
audibly snaps into place.
Turn the bounce diffuser
the notch of the marking tab
with the marking point on the flash
unit housing.
Removal of bounce diffuser
Gently bend up one of the tabs
the bounce diffuser and release it.
Take off the bounce diffuser.
Do not lift and remove the bounce
diffuser at the marking tab

10 The AF auxiliary light

The flash unit is equipped with an AF
auxiliary light which illuminates the
object in dark conditions so that the
camera can focus clearly on the
object or it can be used as illumina-
tion for manual focusing.
The AF auxiliary light is switched on
with button and lights up for
around 10 seconds. If a picture is
taken, the AF auxiliary light switches
off immediately and thus does not
contribute to the lighting.
so that
aligns
on
.
