Metz MECABLITZ 15 MS-1 digital Bedienungsanleitung Seite 74

only with Canon, Nikon, Olympus).
Each group can in turn consists of one
or more slave flash units.
Four independent remote channels
(Channels 1-4) are available, so that
several remote systems in the same
space do not cause mutual disruption.
The setting "Channel ALL" controls all
slave flash units. Slave flash units that
belong to the same remote system
must be set to the same remote chan-
nel. The slave flash units must be able
to pick up the light from the master or
controller flash unit via integrated sen-
sors for remote operation
Adjustment of the flash unit
• Switch the flash units integrated in
the camera or external flash unit on
the camera in the Master or
Controller mode, see operating
manual of the camera or external
flash unit.
• Select an operating mode on the
camera that supports remote opera-
tion
74
15MS-1
V 1 . 0
S E L E C T
S E L
M O D E L L I N G
. L I G H T
O F F O N
S E L
OK
SYSTEM
NIK REMOTE
Ch ALL Gr A
S E L
OK
SYSTEM
OLY REMOTE
Ch ALL Gr A
S E L
OK
• Slide the infrared clamp over the
camera's own flash unit if it is to be
used as controller flash unit. Swivel
the external flash unit so that it can-
not contribute to lighting.
• Switch-on the flash unit with the
main switch .
• Keep the button "AF/SELECT"
pressed down until the following
⊃
message appears in the display:
• Press the button S E L
unit. In the display appears:
• Switch-on (ON) the "MODELLING
LIGHT" function with the button
or switch it off (OFF).
S E L
• Press the button
unit. The most recently used setting
appears in the display, e.g.:
• Press the button
red version for the camera type
used appears in the display:
„CAN REMOTE" (Canon) or
„NIK REMOTE" (Nikon) or
„OLY REMOTE" (Olympus) or
on the flash
on the flash
until the requi-
