• If both the reflectors should be set at
an unequal ratio (Ratio) then press
the buttons to change the
ratio. The ratio can be adjusted in
steps. In the display appears, for
example.
• If you wish to use partial lighting,
then press the button
Following display appears:
• To set partial lighting, press the but-
tons or and thus change the
value. In the display appears, for
example.
The setting thus made will be automa-
tically saved.
7 Operation of flash unit
detached from camera
The flash unit can be detached from
the camera and setup on the base unit
or can be fixed to a tripod with the
tripod thread .
For detached setup, please ensure that
the sensors for remote operation
can receive the light from the camera
flash unit.
SYNC
1:8
P / R
SL Power
P / R
.
P / R
SYNC P
P / R
8 Lighting OK in
remote TTL mode
In camera-specific remote–TTL mode,
R
atio
the button "AF/SELECT"
ves as lighting OK display. If the
object has been sufficiently illumina-
ted, then the red "AF/SELECT"
button lights up for approx.
1/1
3 seconds.
If the object has been over illumina-
ted, then the red "AF/SELECT"
ton blinks for approx. 3 seconds.
ower
1/4
Change the ISO setting or the apertu-
re and try the illumination again.
If the object has been insufficiently
illuminated, then the red "AF/SELECT"
button does not light up.
Change the ISO setting or the apertu-
re and try the illumination again.

9 Swivel reflectors

Both the reflectors
by 10° and 20°. To swivel the reflec-
tors, press the reflector swivel lever
forwards in steps. In the first indexed
position, the reflector is swivelled
also ser-
but-
can be swivelled
