To access the TEST MENU simultaneously press
2.3
See Section 4.5.1
See Section 4.5.2
See Section 4.5.3
See Section 4.5.4
The actions which are highlighted in grey
accurate measurement.
Fluid Control Systems
QUICKSTART

TESTING

Control of
4 mA
Control of
20 mA
„Flow zero" point
Calibration
Simulation of
the outputs
The unit is now ready
6
ENTER
for 5 seconds.
0......9
The Offset mode fixes the output
current of 4mA.
The mode Span fixes the output
of 20mA.
Put the displayed value at 0.00 in
the selected unit when the liquid
in the pipe is not moving.
This is optional although it is
recommended for commissioning
large systems.
must be fully completed for
8045
