Centrometal El-Cm Compact 6 Technische Anleitung Seite 26

EN
Scheme 3. - Electric scheme of the El-Cm Compact 21-27 kW (3-phase connection)
REGULATION
PANEL
L
1
L
2
Connection
voltage
L
3
3x400V
N
1
2
3
Pump
Ordinaly terminal
LEGEND:
26
P
ST
K
K
1
EG EG EG EG EG EG
P - main switch
ST - safety thermostat
K - contactor
EG EG EG EG EG
K - contactor 1
1
EG - electric-heater
RE - electronic of regulation
Technical manual El-Cm Compact
Electric scheme
RE
EG
LED-DISPLAY
