Technical data

Picture 1. - Basic technical dimensions of the electrical boiler El-Cm Compact
280
TECHNICAL DATA
El-Cm Compact
Nom.thermal output
Capacity
Electric boiler mass
Max. operating press.
Max. operating press.
Electric heater
Conductor thickness
Expansion vessel
Inlet/Outlet
Energy efficiency index
Technical manual El-Cm Compact
230
6 9
6 9
(kW)
12 12
(lit.)
39 40
(kg)
2,5 2,5
(bar)
0,25 0,25
(MPa)
2x3 3+6
(kW)
5x2,5 5x2,5
2
(mm )
10 10
(lit.)
1" 1"
(R)
C C
100
2
1 3
0 4
bar
El-Cm
Console of the regulation
64
P
TEHNIKA GRIJANJA
1
0
410
12 15 18
12 15 18
12 12 12
40 41 41
2,5 2,5 2,5
0,25 0,25 0,25
2x6 2x6+3 3x6
5x4 5x4 5x6
10 10 10
1" 1" 1"
C C C
Manometar
Front cover
Digital modulating
regulation
Main switch
21 24 27
21 24 27
12 12 12
42 42 42
2,5 2,5 2,5
0,25 0,25 0,25
3x6+3 4x6 4x6,75
5x6 5x6 5x6
10 10 10
1" 1" 1"
C C C
EN
