Electric scheme
Scheme 2. - Electric scheme of the El-Cm Compact 15-18 kW (3-phase connection)
REGULATION
PANEL
L
1
L
2
Connection
voltage
L
3
3x400V
N
1
2
Pump 3
Ordinaly terminal
LEGEND:
Technical manual El-Cm Compact
P
ST
K
EG EG EG EG EG EG
P - main switch
ST - safety thermostat
K - contactor
EG EG EG
K - contactor 1
1
EG - electric-heater
RE - electronic of regulation
EN
RE
LED-DISPLAY
25
