Stereo Channels:
Stereo Line Input Channels:
Stereo Line Input Channels:
Stereo Line Input Type:
USB In/Out -Connection:
Frequency Response Stereo Line Input:
Amplification Range Stereo Line Input:
Channel Crosstalk:
THD Stereo Line Input:
Impedance Stereo Line Input:
S/N Ratio Stereo Line Input:
Stereo Channel Equalizer Treble:
Stereo channel equalizer hi-mids:
Stereo channel equalizer low-mids
Stereo Channel Equalizer Bass:
Control Elements Channels 17/18 + 23/24
Master Section:
AUX/Effect Send Channels:
AUX/Effect Send Connections:
Balanced Stereo Main Outputs:
Balanced/Unbalanced Stereo Main Output
Connections:
Impedance Balanced Stereo Main Outputs:
Max. Level Balanced/Unbalanced Stereo Main
Outputs:
Stereo Control Room Outputs:
Stereo Control Room Output Connections:
Stereo Outputs (GR OUT):
Group Output Connections:
Headphone Output:
Headphone Output Connections:
Minimum Headphone Impedance:
Digital Effects Processor:
No. of Presets:
Foot Switch Connection DFX Mute:
Controls Master Section:
18
4
2 x 6.3 mm stereo jack (L mono, R) 2 x RCA (cinch)
unbalanced
USB type B (channel 21/22)
10 - 45,000 Hz
50 dB
62 dB
0.0045%
3.7 kOhm
116 dB
+/-15 dB @ 12 kHz
+/-15 dB @ 3 kHz
+/-15 dB @ 500 Hz
+/-15 dB @ 80 Hz
Gain, LINE/USB -switch (channels 21 - 22), EQ Hi, EQ Mid, EQ Mid Freq, EQ Low, EQ
on/off, DFX, AUX Send 1-2 pre (AUX2 pre/post switchable), AUX Send 3-4 post, Chan-
nel Mute, Fader Routing switch (Group 1/2, Group 3/4, Main L+R), Bal, Channel-Fader,
PFL switch
4
4 x 6.3 mm stereo jack, unbalanced
2
2 x 6.3 mm stereo jack, 2 x XLR male
120 ohms
22 dBu (20 dBV)
1
2 x 6.3 mm jack
4
4 x 6.3 mm jack
1
6.3 mm stereo jack
30 ohms
yes
100
6.3 mm jack (foot switch optional)
7-band graphic EQ, EQ On/Off, DFX Presets, DFX Mute, AUX/DFX Send 1 - 4, DFX to
Main, DFX to Aux, Phones, CTRL, GROUP to Main -switch, Phantom Power +48V, Main
Mix Fader, Group Fader, Power, CTRL Room Source MAIN/GR, GR1/2 - GR3/4, Group
Mute, Main Mute
