3. Replacing the loco-tender coupling (Fig. 6)
The model comes with 3 different coupling drawbars:
Short drawbar (58) for showcase, medium drawbar (59) for operation
on radii larger than 1200 mm, large drawbar (60) for operation on radii
larger than 600 mm. Remove the screw (57). Fit the corresponding
coupling drawbar (58, 59 or 60).
4. Replacing the smoke generator / filling with smoke
4.
Pull chimney (50) upwards. Disconnect cable bush for front lamp
(70). Pull frame for boiler door (47) out to the front. Disconnect plug
from smoke generator (48). Remove two screws (49).
Fill the smoke generator from the top through the chimney.
5. Mounting / filling the smoke generator vacuum
Remove cover (54). Solder smoke generator (53) to two existing
cables and put in chimney. Do not replace cover (54).
Fill smoke generator for vacuum brake from the top through the
chimney.
6. Fitting the locomotive buffer cover (Fig. 2)
Remove screw (61), take coupling off (62) and replace with the
enclosed buffer cover (63).
7. Fitting the switching magnet (Fig. 6)
The model is intended for mounting a commercially available, flat
switching magnet, max. 4 mm thick. Adhere the switching magnet
to the mounting plate with contact glue.
8. Dismantling the housing (Fig. 6)
Unhinge control rod (64), remove screws (37, 08 and 07).
Pull housing (02) off to the top.
Note:
9. Replacing the motor (Fig. 6)
Remove the housing (02), see point 8. Unsolder the cables from the
motor. Remove screws (04) and remove cable holder (05). Remove
screws (09) and remove motor bracket (10). Pull motor (11) out to
the top.
Caution: When removing the cable, always pay attention to the right
10. Replacing the boiler PCB (Fig. 6)
Pull chimney (50) upwards. Disconnect cable bush for front lamp
(70). Pull frame for boiler door (47) out to the front. Remove cables
and plugs. Remove two screws (46). Please mark where the
individual cables and plugs were fastened.
G4_5_10000_10001.p65
oil (Fig. 6)
brake (Fig. 6)
During assembly, make sure that the tongues (A) are tucked
into the slots (B).
wiring – otherwise wrong direction of travel.
