Functional Check

To make a simple functional check of the P5210 probe, select a
source that supplies AC line voltage and use the following
procedure. This procedure verifies a majority of the circuitry within
the probe. (For a complete performance verification, refer to the
service manual that accompanies this product.)
1. Use the installation procedure starting on page 10 to connect the
output of the P5210 probe to a measurement instrument.
2. See Table 1 on page 11. Connect the inputs, set the range, and
perform the check as each line of Table 1 indicates.
Table 1: Functional Check
Range
Mode Setting
Differential 100X or
1,000X
Common 100X or
Mode 1,000X
This completes the functional check procedure.
P5210 Instructions
Input 1 Input 2
(+ or –) (– or +) Check
Hot Ground or Measurement instrument
Neutral displays or indicates the line
voltage
Hot (same No signal
connection)
Getting Started
11
