Specifications

The specifications in Tables 2 through 6 apply to a P5210 probe
installed on a Tektronix TDS 460A oscilloscope. When the probe is
used with another oscilloscope, the oscilloscope must have an input
impedance of 1 M and a bandwidth greater than 200 MHz.
The probe must have a warm-up period of at least 20 minutes and be
in an environment that does not exceed the limits described in
Table 2.
Specifications for the P5210 probe fall into three categories:
warranted, typical, and nominal characteristics.

Warranted Characteristics

Warranted characteristics (Tables 2 and 3) describe guaranteed
performance within tolerance limits or certain type-tested require-
ments. Warranted characteristics that have checks in the Perfor-
mance Verification procedure appear in boldface type. The
Performance Verification procedure appears in the P5210 Service
Manual (070-9895-XX, English only).
Table 2: Warranted Electrical Characteristics
DC Common Mode Rejection Ratio
Bandwidth
Gain Accuracy
P5210 Instructions
> 3000:1 at 500 VDC, 20–30 C, <70% RH
DC to 50 MHz (–3dB)
3% at 20–30 C, <70% RH
