Getting Started
Input Leads. The input leads of the differential probe
connect to the probe tips. The connectors are 4 mm
insulated banana plugs and are double insulated for
safety.
NOTE. Use only accessories that are rated to the
maximum input voltage under test.
TekProbe Interface. The TekProbe interface provides
power, signal, and probe characteristic data transfer.
If your oscilloscope does not support the TekProbe
interface, you can use the optional 1103 probe power
supply as an effective interface. Contact your local
Tektronix representative for more information.
Zero Adjust. Use the zero adjust to set the probe output
to the zero reference point prior to making measure-
ments. Use the adjustment tool provided.
P5210 Instructions
7
