Nominal Characteristics

Nominal characteristics (Table 6) describe guaranteed traits, but the
traits do not have tolerance limits.
Table 6: Nominal Electrical Characteristics
Input Type
Output Type
Gain
Overrange Beeper
P5210 Instructions
Specifications
Balanced differential
Single-ended. Source Impedance of 50
drives 1 M oscilloscope input. Load
impedance must be greater than 50 k for
stated accuracy
Switchable: 1/100 (100X) and 1/1,000
(1000X)
Overrange sounds whenever ON, and over
range LED is lit.
