7.

Summary

button display
ERROR
CLEAR
SYSTEM (4-4)
(6-4)
special functions: (please follow sequence!)
1. SYSTEM (4-2)
2. CLEAR
1. SYSTEM (4-2)
2. SYSTEM
861 error indication
Clr deleting the error memory hold button for 0.5 sec.
system display
SYS
functional test
resetting the system
(reconfiguration)
function comments
display: error path, error type
and error frequency
requirement: no currently
existing error
e.g.: 4S / 4M
6S / 4M
Push button and release
Hold button for 2 sec.
Commissioning cycle starts.
Push button and release
Push button for 2 sec.
Reconfiguration is being
performed.
GB
27
