In certain types of system, one modula-
tor acts on several wheels. Combining
two sensors which are allocated to one
modulator can be achieved by axles or
by sides. The table in Section 5.5 shows
the allocations.
After turning the wheels with sensors on
the left-hand
achieved briefly 5 times; wheels on the
right-hand side with sensors are evacu-
ated once and for an extended period.
Any wrong allocation of the A1/Z1 or A2/
Z2 sensors in 6S-3M systems cannot be
detected by means of the pulse pro-
gramme; however, it can be detected
from the display of the Compact Tester.
side, evacuation
PLEASE NOTE: If a type ABS-C ECU
is used, diagnosis cannot be applied to
determine how many modulators have
been installed. For this reason, the
Compact Tester assumes that for each
sensor one modulator has been con-
nected, and this is actuated accordingly.
This means that if the configuration con-
is tains fewer modulators than sensors,
the Tester will attempt to actuate a mod-
ulator which does not actually exist. In
this case, of course the course of pres-
sure cannot be measured on the corre-
sponding wheel by way of the pulse
programme.
