The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
1

Introduction

Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Failure to comply with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of the product and contain
important information for safe, proper and economical op-
eration. Please also observe the applicable national regu-
lations. Read all operating and safety instructions careful-
ly before use and only use the product as described.
Keep the manual and pass it on when you give the prod-
uct to someone else.
2

Proper use

The plate compactor is used to compact loose soils and
free-flowing materials in road construction, landscaping
and general building work. It increases the load-bearing
capacity of the substrate, reduces water permeability and
minimises settlement. It is particularly suitable for paving
work, trenches and general compaction tasks.
ATTENTION
The product is not designed for use on adherent sub-
strates such as clay or hard surfaces such as concrete.
The product may only be used in the intended manner.
Any use beyond this is improper. The user, not the manu-
facturer, is responsible for damages or injuries of any type
resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
In addition, the applicable accident prevention regulations
must be strictly observed.
Other general occupational health and safety-related
rules and regulations must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
3

Product description (Fig. 1-20)

1. Guide handle (folding)
1a. Screw
1b. Washer
1c. Locknut
2. Throttle
2a. Screw
2b. Washer
3. Exhaust pipe
4. Air filter cover
4a. Wing nut (outer)
4b. Wing nut (inner)
4c. Air filter
5. Fuel tank
5a. Fuel filler cap
5b Fuel filter insert
6. Engine
6a. Flex hose
7. Pull starter
8. Eccentric vibration unit
8a. Oil drain plug (eccentric vibration unit oil)
9. Base plate
9a. Holes
10. Chassis
10a. Screw
